Allow user to toggle inline comment margin #1568

Merged
merged 76 commits into from May 16, 2018

Conversation

@jcansdale
Copy link
Collaborator

jcansdale commented Mar 28, 2018

What this PR does

  • New horizontal editor margin is hidden behind feature flag

    • image
  • Adds a margin to the editor window

    • image
  • Clicking on checkbox (or filename/comment bubble) toggles the comment margin

    • image
  • Clicking on view x comments navigates to PR file changes

    • image
  • If there are no PR file comments it will show view changes

    • image
  • If there are no PR file changes the margin won't appear

    • image
  • Right clicking on solution file with active PR branch shows View Changes in # PR button

    • image
  • Right clicking a diff view opened using View Changes in Solution slows the option Open File in Code View. This will open the diff pane in a new code view.

    • This also works with the diff view opened using the default Team Explorer - Changes action Compare with Unmodified...
  • Clicking View Changes in # PR navigates to equivalent line on PR diff view

    • image
  • Clicking View Changes in # PR on file without changes in PR shows warning on status bar

    • image

Metrics

  • NumberOfPullRequestFileMarginToggleInlineCommentMargin - When the user toggles the checkbox to show/hide comment margin

  • NumberOfPullRequestFileMarginViewChanges - When user clicks on view changes/view comments link

  • NumberOfNavigateToPullRequestFileDiff - When user navigates from editor to PR file diff via the GitHub.GoToSolutionOrPRFile command

  • NumberOfPRDetailsNavigateToEditor - When user navigates from PR file diff to editor via the GitHub.GoToSolutionOrPRFile command (NOTE: this counter existed before)


  • ExecuteToggleInlineCommentMarginCommand - When the GitHub.ToggleInlineCommentMargin command is executed (via the checkbox or executing command directly)

Technical notes

  • When opening a comparison window, the DifferenceViewerOptions.ScrollToFirstDiffId global option will be temporarily set to false (see #1631). This lets me immediately set the equivalent caret position when navigating to the the diff view.

Todo

  • Add metrics
    • Add counter for Open File in Code View actions
    • Add counter for executing GoToSolutionOrPullRequestFileCommand
  • Make View File show the comment margin
  • Fix issue where diff view moves to first change. see:

Issues

  • The comments margin doesn't always appear when the comment bubble icon is clicked
    • Same issue when comments margin is always on
  • The UI appears on all text view types (including diff view)

Initial thoughts

My initial impression is that this UI element would be a great opportunity to surface other important information about the current PR. For example:

  • The PR number could be shown there
  • How many (non-inline) comments comments there are and quick navigation to them
  • Show the files that are part of the PR and allow navigation to them
  • Navigate to any of the inline comments on the current PR file
  • Show if there are any unread comments on the PR and notify when they arrive

Lots of opportunities to show things there would be useful to the user and make this UI element more discoverable (e.g. showing the PR number would be handy for navigation and give context to the comment bubble).


Related UI

People will rarely see the following UI. They need to be using an Enterprise/Professional version of VS and be editing a non-source file. This is when editing our GitHub.VisualStudio.vsct file:


When the user clicks on one of the sections, a bubble pops up with a scrollable list of sub-items with an automatic preview of each.


We could do a similar thing, except with a list of inline comments in the file and a preview of each comment. When the user clicks on the comment they're interested it, it would navigate to the inline comment in the source.

Similarly we could have a list of PR review comments, with a preview and navigation to the GitHub PR review UI.

Lastly when the user clicks on the PR number, there could be a list of changed files in the PR and the number of inline comments they have displayed. Clicking in the file would navigate to the PR file diff or editor.

This would give context for the comment margin toggle switch (which I think is too minimal/subtle at the moment).

Tackle in another PR (#1671)

  • Make comments appear on View File (margin appears but no comments 😕)
  • Make comments appear on RHS View Changes in Solution

Fixes #1565

jcansdale added 2 commits Mar 27, 2018
This toggles the GlyphMargin on and off.
It will be changed to toggle the comments margin.
@jcansdale jcansdale force-pushed the fixes/1565-comments-margin-toggle branch from 08ca4e2 to acb8a94 Apr 11, 2018
@jcansdale jcansdale force-pushed the fixes/1565-comments-margin-toggle branch from 113f67a to 37963f6 Apr 13, 2018
jcansdale added 3 commits Apr 16, 2018
We don't want live taggers running and monitoring live files when margin isn't visible.
Only monitor live file when InlineCommentMarginEnabled.
@jcansdale jcansdale changed the title [Spike] Allow user to toggle inline comment margin [wip] Allow user to toggle inline comment margin Apr 18, 2018
We only need live updates is the margin is actually visible, not simply if it is enabled.
jcansdale added 8 commits May 11, 2018
Increment NumberOfPullRequestFileMarginToggleInlineCommentMargin when
checkbox is toggled.
Increment NumberOfPullRequestFileMarginViewChanges when view
changes/comments is clicked.
This allows navigation from View Changes in Solution to Code View.
It also allows navigation from the default Team Explorer changes diff
view (Compare with Unmodified...) to code view.
Add metric for navigating from editable diff (e.g. `View Changes in
Solution`) to code view.
Add metric for number of times
ExecuteGoToSolutionOrPullRequestFileCommand is executed.
Move NumberOfPRDetailsNavigateToEditor next to related metrics and
comment that it should be renamed to NumberOfNavigateToEditor.
@meaghanlewis
Copy link
Contributor

meaghanlewis commented May 14, 2018

Hey @jcansdale here are a few things I noticed today:

  1. The command GitHub.ToggleInlineCommentMargin is not actually toggling the comment margin for me. Although every time I execute the command the metric: ExecuteToggleInlineCommentMarginCommand increments just fine.

  2. Some of the metrics don't seem to be incrementing correctly.

NumberOfNavigateToCodeView is always 0 even after I select the option
image 2

NumberOfPullRequestFileMarginViewChanges is always 0 even after I click on the view comments link.
39930471-b713f17c-5532-11e8-8d3b-8f186d52b073

This is a bit more vague, but I've noticed that some metrics aren't incrementing regularly for: NumberOfPRDetailsNavigateToEditor, NumberOfNavigateToPullRequestFileDiff, or NumberOfPullRequestFileMarginToggleInlineCommentMargin. Instead when I perform those actions it appears to increment ExecuteGoToSolutionOrPullRequestFileCommand instead.

metrics for viewing inline comments

@StanleyGoldman
Copy link
Contributor

StanleyGoldman commented May 14, 2018

Should it locate me to the comment when i click the "view comments" in the task bar?

@jcansdale
Copy link
Collaborator Author

jcansdale commented May 15, 2018

@StanleyGoldman,

Should it locate me to the comment when i click the "view comments" in the task bar?

Good point. It doesn't locate you on the comment, it simply navigates to show changes in the PR (that happens to have x number of comments). The use can then view an already open comment or navigate to the next/previous comment.

Maybe, view changes in PR (x comments) would be clearer?

@grokys
grokys approved these changes May 15, 2018
Copy link
Contributor

grokys left a comment

A few comments on the code, but this looks good for a beta feature. I find the toggle control slightly confusing at the moment, but I understand that this feature needs iterating on, so lets discuss that elsewhere.

// HACK: We need to wait here for the inline comment tags to initialize so we can find the next inline comment.
// There must be a better way of doing this.
await Task.Delay(1500);
RaiseWhenAvailable(Guids.CommandSetString, PkgCmdIDList.NextInlineCommentId, param);

This comment has been minimized.

@grokys

grokys May 15, 2018 Contributor

I thought this hack was no longer necessary with DifferenceViewerOptions.ScrollToFirstDiffId?

This comment has been minimized.

@jcansdale

jcansdale May 15, 2018 Author Collaborator

So did I! 😢 It seems there's another issue where the NextInlineCommentId depends on the comment margin tags having been updated in order to navigate to the next comment. Before the tags have been refreshed, this command is unavailable and it would crash when attempting to execute the command.

We should attempt to fix this in another PR.

{
[Export(typeof(EditorOptionDefinition))]
[Name(OptionName)]
public class InlineCommentMarginEnabled : ViewOptionDefinition<bool>

This comment has been minimized.

@grokys

grokys May 15, 2018 Contributor

I've never used this API, so I'm missing something here, but the only thing that seems to be used from this class is OptionName. Do we need to create a subclass of ViewOptionDefinition if we only use the name? Why not use an instance of this class as they key when getting options?

This comment has been minimized.

@jcansdale

jcansdale May 15, 2018 Author Collaborator

By exporting ViewOptionDefinition we declare than a new options exists on the text views (and give it a default value). I probably shouldn't be using OptionName directly and should be importing the option and using the Key property. This gives us type information for the property.

I've changed OptionName to private and am using Key in the latest commit.

@@ -118,7 +118,8 @@
Text="{Binding Body, UpdateSourceTrigger=PropertyChanged}"
TextWrapping="Wrap"
VerticalAlignment="Center"
GotFocus="ReplyPlaceholder_GotFocus">
GotFocus="ReplyPlaceholder_GotFocus"
SpellCheck.IsEnabled="True">

This comment has been minimized.

@grokys

grokys May 15, 2018 Contributor

Wasn't there another PR with this feature?

This comment has been minimized.

@jcansdale

jcansdale May 15, 2018 Author Collaborator

Well, there will be. I didn't try to sneak this one in, seriusly! ;-)

namespace GitHub.Commands
{
[Export(typeof(IGoToSolutionOrPullRequestFileCommand))]
public class GoToSolutionOrPullRequestFileCommand : VsCommand, IGoToSolutionOrPullRequestFileCommand

This comment has been minimized.

@grokys

grokys May 15, 2018 Contributor

Could we have a comment here (and on the interface) as it's not totally clear from the class name what this command will do.

This comment has been minimized.

@jcansdale

jcansdale May 15, 2018 Author Collaborator

Done. I hope it make sense. Let me know if it isn't clear.

jcansdale added 6 commits May 15, 2018
By using Key we can take advantage of the option's type information.
No need to go through IGitHubServiceProvider.
Use InlineCommentTextViewOptions for typed editor option keys.
@jcansdale
Copy link
Collaborator Author

jcansdale commented May 15, 2018

@meaghanlewis,

Some of the metrics don't seem to be incrementing correctly.

Thanks for the heads up! I don't understand why this is happening. 😕 I'll investigate more tomorrow.

@jcansdale
Copy link
Collaborator Author

jcansdale commented May 16, 2018

@meaghanlewis,

The command GitHub.ToggleInlineCommentMargin is not actually toggling the comment margin for me. Although every time I execute the command the metric: ExecuteToggleInlineCommentMarginCommand increments just fine.

The GitHub.ToggleInlineCommentMargin command toggles an option on the current editor that determines whether the comment margin is visible in certain circumstances (the user is on a PR branch and editing a file that has changed in the PR).

When you execute GitHub.ToggleInlineCommentMargin from the Command Window, it will toggle this option on the command window itself. If you were to bind the command to a keyboard shortcut, you should find it works as expected (I've bound it to Alt+G, Alt+T).

@jcansdale jcansdale merged commit 6cf4a55 into master May 16, 2018
2 checks passed
2 checks passed
continuous-integration/appveyor/branch AppVeyor build succeeded
Details
continuous-integration/appveyor/pr AppVeyor build succeeded
Details
@jcansdale jcansdale deleted the fixes/1565-comments-margin-toggle branch May 16, 2018
@meaghanlewis
Copy link
Contributor

meaghanlewis commented May 17, 2018

@jcansdale it's still hard for me to understand what GitHub.ToggleInlineCommentMargin. I don't see it have any affect on whether the comment margin is visible or not when viewing a changed file on a PR (with the branch checked out). Could you show me perhaps?

@meaghanlewis
Copy link
Contributor

meaghanlewis commented May 17, 2018

Also, @sguthals and I were noticing that when enabling or disabling the feature flag, that a file (or files) need to be closed and reopened to actually see the options to toggle the inline comment margin. This is probably to be expected, and I'm sure users won't just be toggling the flag often, but just wanted to bring it up.

@jcansdale
Copy link
Collaborator Author

jcansdale commented May 21, 2018

@meaghanlewis,

it's still hard for me to understand what GitHub.ToggleInlineCommentMargin. I don't see it have any affect on whether the comment margin is visible or not when viewing a changed file on a PR (with the branch checked out).

I think the confusion might be that it's a per-editor view setting, not a global show comments in the margin for all file setting. It is triggered when you click on the check box (when the horizontal margin is visible).


I made it that way because the horizontal margin is constructed per-editor view. It might make more sense for it to be a global show the editor margin setting. The checkbox would remain set when moving between PR files and executing GitHub.ToggleInlineCommentMargin would toggle the checkbox on and off. I think that would be a lot less confusing!

Also, @sguthals and I were noticing that when enabling or disabling the feature flag, that a file (or files) need to be closed and reopened to actually see the options to toggle the inline comment margin. This is probably to be expected, and I'm sure users won't just be toggling the flag often, but just wanted to bring it up.

Yes, that is by design. To make it dynamic, the margin would need to be loaded but hidden. I've made it so the switch completely disables this functionality. I got bitten by this once before when hidden functionality was causing issues.
