Description
English: Project-Orion propulsion-module with pusher plate, two-stage shock absorber and pulse unit storage and ejection compartment.
Deutsch: Projekt-Orion Antriebsmodul, mit Prallplatte, zweistufigen Stoßdämpfer und Treibladungslager sowie Treibladungsausstoßsystem.
Date
Source Nuclear Pulse Space Vehicle Study Vol III - Conceptual Vehicle Designs and Operational Systems, Fig 2.5, p 10.
Author NASA
